Gas condensing boiler Crystal III 35/40 kW combi
CRYSTAL III
CRYSTAL III – a modern condensing boiler that combines the highest efficiency, user comfort, and safe operation.
Thanks to advanced flame modulation technology, a soft ignition function, and quiet operation, CRYSTAL III perfectly adapts to your home's current heating needs. This economical and exceptionally ecological solution is suitable for both new buildings and modernized heating systems. Choosing the CRYSTAL III boiler ensures not only thermal comfort but also real savings in everyday operation. - Energy class: A
- OPEN-THERM communication system
- Remote control of boiler parameters from a room thermostat
- Modern, high-efficiency heat exchanger
- Single-coil heat exchanger made of stainless steel
- Cascade operation possible (up to 4 boilers)
- Highly efficient circulation pump
- Fan with variable speed control (electronically controlled)
- Stainless steel cylindrical burner with low NOx emissions (Class 6)
- Complete safety system
- Electronic flame modulation
- Compatible with multi-zone modules for heating systems
- Electrical consumption at part load elmin [kW]:
- 0.054
- Maximum water pressure [bar]:
- 3
- Boiler useful efficiency at nominal load and 70°C average water temperature [%]:
- 98
- Domestic water connection:
- G1/2
- Nitrogen dioxide emission level [mg/kWh]:
- 39.7
- Standard setpoint temperature [°C]:
- 40 - 80
- Nitrogen oxide (NOx) emission class:
- 6
- Overall dimensions (H x W x D) [mm]:
- 775 x 400 x 310
- Heating water and gas connection:
- G3/4
- Water pressure [bar]:
- 0,1 - 6,0
- Nominal boiler heat output (at 80/60°C) [kW]:
- 5,0 - 39,2
- Degree of protection (IP rating):
- IPX4D
- Water temperature control range [°C]:
- 30 - 60
- Boiler weight [kg]:
- 40
- Standby power consumption PSB [kW]:
- 0.005
- Seasonal space heating energy efficiency class:
- A
- Reduced setpoint temperature [°C]:
- 25 - 55
- Electrical consumption at full load elmax [kW]:
- 0.102
- Useful heat output at 30% nominal output P1 (for modulating boilers 30% arithmetic mean) [kW]:
- 11.5
- Expansion vessel capacity [dm³]:
- 8
- Heat exchanger material:
- INOX stainless steel
- Sound power level LWA [dB]:
- 50.8
- Type and voltage of electrical power supply:
- ~ 230 ±10%/ 50Hz V
- Heating capacity (at 80/60°C) [kW]:
- 5,0 - 34,0
- Maximum CH operating temperature [°C]:
- 95
- Domestic water flow rate for Δt 30K [dm³/min]:
- 19
- Heat load [kW]:
- 5,2 - 35,6
- Useful efficiency η1 [%]:
- 97.5
- Seasonal space heating energy efficiency ηs [%]:
- 94
- Pump head at zero flow [bar]:
- 0.7
- Water heating energy efficiency ηwh [%]:
- 88
- Water heating energy efficiency class:
- A
- Useful efficiency η4 [%]:
- 88.5
- Load profile:
- XL
- Useful heat output at nominal heat output P4 (for modulating boilers arithmetic mean of max and min) [kW]:
- 34.8
- Nominal heat input [kW]:
- 5,2 - 41,0
- Heating capacity (at 50/30°C) [kW]:
- 5,5 - 38,0
- Minimum water flow [dm³/min]:
- 2
- Boiler useful efficiency at part load and 30°C return water temperature [%]:
- 108
