Gas condensing boiler Euro Comfort 25/30 kW combi
EURO COMFORT
Gas condensing boilers - one of the most modern devices in the European market. Thanks to clear and intuitive control panel these boilers are very easy to use. Wide range of modulation allows the boilers to heat very small areas and objects with low heat demand. An innovative software enables adaptation of the device to any type of installation.
built-in coaxial adapter Ø60/Ø100 with measuring points
modern heat exchanger:
single spacious coil made of stainless steel
resistant to dirt accumulation
low hydraulic resistance
new generation burner provides wide range of modulation (12%-100%)
high-efficiency modulating pump controlled via PWM signal (EEI≤0,23) with automatic airvent
electronically controlled modulating fan
environmentally friendly: low level of NOx emission (6th class)
complete system of protection
modern control panel allows full self-diagnosis and adjustment of boiler parameters to any installation
system boilers have built-in 3-way valve that ensures boiler cooperation with DHW tank
system boilers are equipped with tank NTC sensor
optimised management of the heating system in cooperation with SIM module and/or i-3 PLUS zone manager
possibility to connect regulators with On/Off, 0-10V and Open-Therm communication protocol
remote control via TERMET COMFORT SYSTEM with possibility of expanding with additional zones
cooperates with MX01 extension module
- Maximum water pressure [bar]:
- 3
- Heating capacity (at 80/60°C) [kW]:
- 3,7 - 24,0
- Boiler useful efficiency at nominal load and 70°C average water temperature [%]:
- 98
- Domestic water connection:
- G1/2
- Standard setpoint temperature [°C]:
- 40 - 80
- Heating water and gas connection:
- G3/4
- Nitrogen dioxide emission level [mg/kWh]:
- 38
- Domestic water flow rate for Δt 30K [dm³/min]:
- 14
- Nominal heat input [kW]:
- 3,8 - 30,6
- Degree of protection (IP rating):
- IPX4D
- Seasonal space heating energy efficiency class:
- A
- Reduced setpoint temperature [°C]:
- 25 - 55
- Expansion vessel capacity [dm³]:
- 8
- Heat exchanger material:
- INOX stainless steel
- Electrical consumption at full load elmax [kW]:
- 0,077
- Type and voltage of electrical power supply:
- ~ 230 ±10%/ 50Hz V
- Nominal boiler heat output (at 80/60°C) [kW]:
- 3,7 - 30,0
- Maximum CH operating temperature [°C]:
- 95
- Overall dimensions (H x W x D) [mm]:
- 775 x 400 x 300
- Sound power level LWA [dB]:
- 49
- Electrical consumption at part load elmin [kW]:
- 0,059
- Heating capacity (at 50/30°C) [kW]:
- 4,1 - 26,5
- Connection to flue gas duct:
- concentric Φ80/125; concentric Φ60/100 or 2 single Φ80
- Water heating energy efficiency class:
- A
- Useful efficiency η1 [%]:
- 99,7
- Boiler weight [kg]:
- 34,5
- Useful heat output at nominal heat output P4 (for modulating boilers arithmetic mean of max and min) [kW]:
- 24,3
- Seasonal space heating energy efficiency ηs [%]:
- 95
- Useful efficiency η4 [%]:
- 88,9
- Standby power consumption PSB [kW]:
- 0,004
- Pump head at zero flow [bar]:
- 0,6
- Load profile:
- XL
- Useful heat output at 30% nominal output P1 (for modulating boilers 30% arithmetic mean) [kW]:
- 8,0
- Boiler useful efficiency at part load and 30°C return water temperature [%]:
- 108
