Gas condensing boiler Euro Comfort 35 kW system
EURO COMFORT
Gas condensing boilers - one of the most modern devices in the European market. Thanks to clear and intuitive control panel these boilers are very easy to use. Wide range of modulation allows the boilers to heat very small areas and objects with low heat demand. An innovative software enables adaptation of the device to any type of installation.
built-in coaxial adapter Ø60/Ø100 with measuring points
modern heat exchanger:
single spacious coil made of stainless steel
resistant to dirt accumulation
low hydraulic resistance
new generation burner provides wide range of modulation (12%-100%)
high-efficiency modulating pump controlled via PWM signal (EEI≤0,23) with automatic airvent
electronically controlled modulating fan
environmentally friendly: low level of NOx emission (6th class)
complete system of protection
modern control panel allows full self-diagnosis and adjustment of boiler parameters to any installation
system boilers have built-in 3-way valve that ensures boiler cooperation with DHW tank
system boilers are equipped with tank NTC sensor
optimised management of the heating system in cooperation with SIM module and/or i-3 PLUS zone manager
possibility to connect regulators with On/Off, 0-10V and Open-Therm communication protocol
remote control via TERMET COMFORT SYSTEM with possibility of expanding with additional zones
cooperates with MX01 extension module
- Pump head at zero flow [bar]:
- 0,7
- Maximum water pressure [bar]:
- 3
- Boiler weight [kg]:
- 35,5
- Boiler useful efficiency at nominal load and 70°C average water temperature [%]:
- 98
- Standard setpoint temperature [°C]:
- 40 - 80
- Heating water and gas connection:
- G3/4
- Heating capacity (at 80/60°C) [kW]:
- 5,5 - 34,5
- Degree of protection (IP rating):
- IPX4D
- Seasonal space heating energy efficiency class:
- A
- Reduced setpoint temperature [°C]:
- 25 - 55
- Expansion vessel capacity [dm³]:
- 8
- Heat exchanger material:
- INOX stainless steel
- Type and voltage of electrical power supply:
- ~ 230 ±10%/ 50Hz V
- Maximum CH operating temperature [°C]:
- 95
- Overall dimensions (H x W x D) [mm]:
- 775 x 400 x 300
- Useful heat output at 30% nominal output P1 (for modulating boilers 30% arithmetic mean) [kW]:
- 11,6
- Seasonal space heating energy efficiency ηs [%]:
- 94
- Domestic water connection:
- G3/4
- Electrical consumption at full load elmax [kW]:
- 0,098
- Useful efficiency η1 [%]:
- 98,5
- Connection to flue gas duct:
- concentric Φ80/125; concentric Φ60/100 or 2 single Φ80
- Electrical consumption at part load elmin [kW]:
- 0,063
- Useful heat output at nominal heat output P4 (for modulating boilers arithmetic mean of max and min) [kW]:
- 35,0
- Useful efficiency η4 [%]:
- 88,5
- Standby power consumption PSB [kW]:
- 0,001
- Heating capacity (at 50/30°C) [kW]:
- 6,0 - 38,0
- Sound power level LWA [dB]:
- 51
- Boiler useful efficiency at part load and 30°C return water temperature [%]:
- 108
- Nitrogen dioxide emission level [mg/kWh]:
- 36
