Gas condensing boiler Gold Plus II 36 kW system
GOLD PLUS II
The GOLD PLUS II series condensing boilers are innovative, modern devices suitable for both radiator and underfloor heating systems, as well as for domestic hot water preparation. They are ideal for installation in both new buildings and modernized installations. Their elegant and modern design makes them a perfect fit for any interior. Thanks to the use of the latest generation of components, GOLD PLUS II condensing boilers are extremely environmentally friendly. You can manage your heating online using the Termet Comfort System Basic Package. Key advantages:
- Energy class: A
- Internet control - Room temperature management via smartphone or tablet using the Termet Comfort System package
- Use of the latest generation stainless steel heat exchanger with a single coil
- Extremely wide power modulation range: from 17% to 100%
- Highly efficient circulation pump
- Fan with smooth speed control (electronically controlled)
- Stainless steel cylindrical burner with low NOx emissions (Class 6)
- Hydraulic group in the form of a hydroblock mounted on quick connectors
- Complete safety system
- Open-Therm communication system using the CR11011 controller
- Maximum water pressure [bar]:
- 3
- Boiler weight [kg]:
- 38.1
- Boiler useful efficiency at nominal load and 70°C average water temperature [%]:
- 98
- Standard setpoint temperature [°C]:
- 40 - 80
- Nitrogen oxide (NOx) emission class:
- 6
- Heating water and gas connection:
- G3/4
- Degree of protection (IP rating):
- IPX4D
- Heating capacity (at 50/30°C) [kW]:
- 4,0 - 38,9
- Water temperature control range [°C]:
- 30 - 60
- Seasonal space heating energy efficiency class:
- A
- Reduced setpoint temperature [°C]:
- 25 - 55
- Nitrogen dioxide emission level [mg/kWh]:
- 43
- Heat exchanger material:
- INOX stainless steel
- Electrical consumption at full load elmax [kW]:
- 0.119
- Type and voltage of electrical power supply:
- ~ 230 ±10%/ 50Hz V
- Maximum CH operating temperature [°C]:
- 95
- Seasonal space heating energy efficiency ηs [%]:
- 93.2
- Overall dimensions (H x W x D) [mm]:
- 793 x 400 x 342
- Pump head at zero flow [bar]:
- 0.7
- Useful efficiency η1 [%]:
- 97.6
- Standby power consumption PSB [kW]:
- 0.002
- Useful heat output at nominal heat output P4 (for modulating boilers arithmetic mean of max and min) [kW]:
- 35.2
- Useful heat output at 30% nominal output P1 (for modulating boilers 30% arithmetic mean) [kW]:
- 11.6
- Useful efficiency η4 [%]:
- 89.5
- Heat load [kW]:
- 3,7 - 36,0
- Heating capacity (at 80/60°C) [kW]:
- 3,6 - 35,3
- Electrical consumption at part load elmin [kW]:
- 0.061
- Sound power level LWA [dB]:
- 51
- Boiler useful efficiency at part load and 30°C return water temperature [%]:
- 108
