Gas water heater Termaq Electronic Eco GE-24-02
Termaq Electronic Eco gas instantaneous water heaters are modern devices for preparing domestic hot water. They are designed for installation in kitchens and bathrooms in both old and modernized buildings. Thanks to the innovative heat exchanger and burner design, these heaters meet the requirements of the ErP Directive (nitrogen oxide emissions below 56 mg/kWh). These devices are therefore ecological and economical, and their attractive design makes them a decorative element in the most modern interiors.
• Electronic battery ignition
• Innovative water-cooled burner significantly reduces carbon monoxide and nitrogen emissions
• Copper heat exchanger manufactured using modern technology, ensuring high efficiency
• Very short start-up time
• Heater power is regulated proportionally to the amount of water flowing, ensuring a constant water temperature
• Latest-generation integrated water-gas unit
• Uniform and very quiet operation
• Gas leak protection
• Chimney draft sensor
- Operating water pressure [bar]:
- 0,2 - 10,0
- Minimum heat input [kW]:
- 10.5
- Heater weight [kg]:
- 12.1
- Flue gas outlet connection (internal diameter) [mm]:
- 132
- Nominal heat output [kW]:
- 24
- Nominal heat input [kW]:
- 27.3
- Hot water flow rate (Δt ≤ 50°C) [dm³/min]:
- 3,6 - 7,0
- Overall dimensions (H x W x D) [mm]:
- 590 x 360 x 230
- Sound power level LWA [dB]:
- 60
- Maximum outlet water temperature [°C]:
- 65
- Hot water flow rate (Δt ≤ 25°C) [dm³/min]:
- 7,0 - 14,0
- Water heating energy efficiency ηwh [%]:
- 75
- Thermal efficiency [%]:
- 88
- Minimum heat output [kW]:
- 9.1
- Water heating energy efficiency class:
- A
- Ignition type:
- electronic, battery
- Hot water connection:
- G1/2
- Cold water connection:
- G1/2
- Gas connection:
- G3/4
- Load profile:
- L
