Heat pump Termet Heat Gold 9 DC
TERMET HEAT
TERMET HEAT GOLD is an exceptionally eco-friendly heat source because it utilizes energy stored in the air.
The components used in these pumps ensure high performance and technical parameters, achieving an A+++ energy efficiency class for space heating.
Additionally, by using the SmartGrid function, which enables intelligent integration of pumps with photovoltaic panels, you can achieve even greater savings by taking advantage of variable tariffs.
Our reversible pumps perform several functions – they can be used not only for space heating, but also for heating domestic hot water, or for cooling in the summer.
• Modern, reversible, monobloc heat pump
• Can be installed outdoors
• Highly efficient Mitsubishi inverter compressor
• Electronic expansion valve
• Eco-friendly R32 refrigerant (GWP only 675)
• Extremely economical heat pump with A+++ (A7/W35) rating
• Wide supply temperature range of 30-60°C
• Weather-resistant sheet metal housing
• Quiet operation
• Easy heat pump control using the HPmulti controller – the controller is equipped with a color touchscreen
• Ability to control and monitor heat pump operating parameters online using the ecoNET300 module
• HPmulti controller and ecoNET300 module included with the heat pump
- Electrical power input (A7/W35) [kW]:
- 2.1
- Seasonal space heating energy efficiency class:
- A+++
- Heating system temperature range [°C]:
- to 55
- Heating capacity (A7/W35) [kW]:
- 8.8
- Overall dimensions (H x W x D) [mm]:
- 1120 x 480 x 712
- Frost protection for domestic hot water:
- yes
- Sound power level Lw [dB]:
- 64
- Refrigerant charge in the system [kg]:
- 1.2
- Lower source (air) temperature range [°C]:
- from -25 to 43
- GWP:
- 675
- Cooling capacity [kW]:
- 8.4
- COP (A7/W35):
- 4,5
- Compressor:
- inverted
- EER:
- 3,5
- Weight [kg]:
- 80
- Supply:
- 230V/50Hz
- Defrost method:
- reversible
- Electrical power input (cooling) [kW]:
- 2.4
- Width [mm]:
- 1120
- Location:
- outdoor
- Refrigerant:
- R32
- Degree of protection (IP rating):
- IPX4
